| Format | Format |
| Socket | 2011 |
| Chipset | Intel X79 |
| Chipset graphique | Non intégré
Technologie Multi-cartes graphiques : Support 4-Way / 3-Way / 2-Way AMD CrossFireX / NVIDIA SLI technology |
| Processeurs supportés | Intel Core i7 sur Socket LGA 2011
Le Cache L3 varie selon le processeur choisi.
Visitez le site www.gigabyte.fr pour la liste des processeurs supportés. |
| Mémoire | 8 x DIMM, max. 64 Go DDR3 2133/1866/1600/1333/1066 MHz 1.5V
Support non-ECC memory modules
4 channel memory architecture
Support for Extreme Memory Profile (XMP) memory modules
Si la capacité de la mémoire installée est de 4 Go ou supérieure, il se peut que le système d|exploitation Windows 32 bits ne reconnaisse pas la totalité de mémoire : soit moins de 3 Go. C|est pourquoi nous vous recommandons d|installer un système d|exploitation Windows 64 bits si vous souhaitez utiliser 4 Go ou plus de mémoire. |
| Slots d|extension | 2 x PCI-Express 3.0 x16, running at x16 (PCI-ExpressX16_1, PCI-ExpressX16_2)
* Pour optimiser les performance lors de l|installation d|une seule carte graphique, veuillez utiliser le slot PCI-ExpressX16.
1 x PCI-Express 3.0 x16, running at x8 (PCI-ExpressX8)
2 x PCI-Express 2.0 x1
1 x PCI |
| Stockage | Chipset :
2 x SATA 6Gb/s connectors (SATA3 0/SATA3 1)
4 x SATA 3Gb/s connectors (SATA2 2~SATA2 5)
Support RAID 0, RAID 1, RAID 5, RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the system performance of the RAID set may vary depending on the devices being connected.
3 x Marvell 88SE9172 chips :
4 x SATA (6 Gb/s) (GSATA3 6~GSATA3 9)
2 x eSATA (6 Gb/s) dont 1 x eSATA/USB Combo inclus
Support SATA RAID 0, RAID 1 |
| LAN | Intel GbE LAN (10/100/1000 Mbit/s) |
| Audio | 8 canaux
Realtek ALC898 codec High Definition Audio 2/4/5.1/7.1-channel
Support for Dolby Home Theater
Support for S/PDIF Out |
| USB / Firewire | Chipset :
14 x USB 2.0/1.1 (8 ports on the back panel, including 1 eSATA/USB Combo, 6 ports available through the internal USB headers)
2 x Fresco FL1009 chips :
4 x USB 3.0/2.0 (2 ports on the back panel, 2 ports available through the internal USB headers)
FireWire VIA VT6308 chip :
2 x IEEE 1394a (1 port on the back panel, 1 port available through the internal IEEE 1394a header) |
| Fonctionnalités | Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune (les fonctionnalités peuvent varier selon le modèle de la carte mère)
Support for Smart 6
Support for eXtreme Hard Drive (X.H.D)
Support for ON/OFF Charge
Support for Cloud OC
Support for TouchBIOS
Support for 3TB+ Unlock
Support for Q-Share |
| Connecteurs panneau arrière | 1 x clavier/souris PS/2
1 x CPU overclocking button
1 x BIOS switch button
1 x Clear CMOS button
1 x IEEE 1394
7 x USB 2.0/1.1
2 x USB 3.0/2.0
1 x eSATA/USB Combo connector
1 x eSATA 6Gb/s connector
1 x RJ45
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In/Mic In, Line Out) |
| Connecteurs E/S internes | 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
4 x SATA 3Gb/s connectors
1 x CPU fan header
4 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
3 x USB 2.0/1.1 headers
1 x USB 3.0/2.0 header
1 x IEEE 1394a header
1 x Clear CMOS jumper
1 x Trusted Platform Module (TPM) header |
| BIOS | 2 x 64 Mbit flash
Use of licensed AMI EFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Dimensions | 305 x 264 mm |
| Réf. constructeur | X79-UD5 |
| Constructeur | Gigabyte |
| Garantie | 1ère année retour atelier Microinfo
2 années supplémentaires direct Gigabyte |
